“艾云尼”台风龙卷天气过程分析

doi:10.3969/j.issn.1673-503X.2020.02.003

Abstract

Abstract:

Based on the data from the conventional and automatic weather stations, Doppler radar, network videos, the disaster investigation and so on, the tornado weather process of No.1804 Ewiniar typhoon was analyzed.The results show that the tornado occurs on the right and rear side of the direction of typhoon Ewiniar after landing, with a strength level of EF1.The favorable circulation background includes the divergence suction at a high level, strong southeasterly jet stack at the middle and low level, and the lifting trigger of the mesoscale convergence line at the ground.The properties of atmosphere convective parameters are weak convective available potential energy and convective inhibitory energy, strong vertical wind shear at a low level, and low elevation condensation height and large relative helicity of a storm.The convective storm that produced the tornado is a low-mass micro-supercell one, and the tornado appears in the weak echo area of hook echo.On the velocity diagram, the meso-cyclone appears about 30 min ahead.The rotation speed of the meso-cyclone increases to the largest level near the occurrence of a tornado.Its size decreases, and its bottom height reaches to the minimum.All of these have a certain indicating effect for the early warning of the tornado.

Key words: Typhoon-tornado, Environmental background, Radar echo characteristics, Meso-cyclone

CLC Number:

P458.3

Jiang-ling ZHI. Analysis of the tornado weather process of Ewiniar typhoon[J]. Journal of Meteorology and Environment, 2020, 36(2): 20-27.

Figures/Tables 8

Fig.1

Table 1

Fig.2

Table 2

Fig.3

Fig.4

Fig.5

Fig.6

References 28

1	范雯杰, 俞小鼎. 中国龙卷的时空分布特征[J]. 气象, 2015, 41 (7): 793- 805.
2	McCaul E W . Buoyancy and shear characteristics of hurricane-tornado environments[J]. Monthly Weather Review, 1991, 119 (8): 1954- 1978.
3	黄先香, 炎利军, 王硕甫, 等. 佛山市龙卷风活动的特征及环流背景分析[J]. 广东气象, 2014, 36 (3): 20- 24.
4	郑媛媛, 张备, 王啸华, 等. 台风龙卷的环境背景和雷达回波结构分析[J]. 气象, 2015, 41 (8): 942- 952.
5	朱红蕊, 张洪玲, 孙爽, 等. 1956—2011年黑龙江省龙卷风气候特征[J]. 气象与环境学报, 2015, 31 (3): 98- 103.
6	陈传雷, 吴晓峰, 孙晓魏, 等. 辽宁省强对流天气的气候特征分析[J]. 气象与环境学报, 2010, 26 (3): 27- 33.
7	王婷婷, 王宁, 姚瑶, 等. 东北冷涡背景下两类龙卷形成机制的对比分析[J]. 气象与环境学报, 2017, 33 (6): 9- 15.
8	俞小鼎, 郑媛媛, 廖玉芳, 等. 一次伴随强烈龙卷的强降水超级单体风暴研究[J]. 大气科学, 2008, 32 (3): 508- 522.
9	张建云, 张持岸, 葛元, 等. 1522号台风外围佛山强龙卷X波段双偏振多普勒雷达反射率因子特征[J]. 气象科技, 2018, 46 (1): 163- 169.
10	Donaldson R J . Vortex signature recognition by a doppler radar[J]. Journal of Applied Meteorology, 1970, 9 (4): 661- 670.
11	刘希文, 李得勤, 韦惠红, 等. 2013年湖北地区两次雷暴大风过程环境及雷达回波特征[J]. 气象与环境学报, 2018, 34 (1): 1- 10.
12	Fujita T T , Brandbury D L , van Thullenar C F . Palm Sunday tornadoes of April 11, 1965[J]. Monthly Weather Review, 1970, 98 (1): 29- 69.
13	Fujita T T.Proposed characterization of tornadoes and hurricanes by area and intensity[M]//University of Chicago, Satellite and Mesometeorology Research Project.Society for Medieval and Renaissance Philosophy Research Paper Number 91.Chicago, USA: Satellite and Mesometeorology Research Project.Department of the Geophysical Sciences, the University of Chicago, 1971: 42.
14	McDonald J R . A recommendation for an enhanced Fujita scale(EF-scale)[M]. Lubbock, Texas: Wind Science and Engineering Center, Texas Technology University, 2006.
15	郑永光, 田付友, 周康辉, 等. 雷暴大风与龙卷的预报预警和灾害现场调查[J]. 气象科技进展, 2018, 8 (2): 55- 61.
16	Edwards R , LaDue J G , Ferree J T , et al. Tornado intensity estimation:past, present, and future[J]. Bulletin of the American Meteorological Society, 2013, 94 (5): 641- 653.
17	Frelich L E , Ostuno E J . Estimating wind speeds of convective storms from tree damage[J]. Electronic Journal of Severe Storms Meteorology, 2012, 7 (9): 1- 19.
18	郑永光, 田付友, 孟智勇, 等. "东方之星"客轮翻沉事件周边区域风灾现场调查与多尺度特征分析[J]. 气象, 2016, 42 (1): 1- 13.
19	肖柳斯, 谌志刚, 胡东明, 等. 强台风"彩虹"衍生的龙卷风特征分析[J]. 气象与环境学报, 2017, 33 (3): 21- 28.
20	郑永光, 朱文剑, 姚聃, 等. 风速等级标准与2016年6月23日阜宁龙卷强度估计[J]. 气象, 2016, 42 (11): 1289- 1303.
21	Thompson R L, Edwards R, Hart J A.An assessment of supercell and tornado forecast parameters with RUC-2 model close proximity soundings[C]//American Meteorological Society.21st Conference on severe local storm.San Antonio, TX: American Meteorological Society, 2000: 595-598.
22	Craven J P , Brooks H E . Baseline climatology of sounding derived parameters associated with deep, moist convection[J]. National Weather Digest, 2004, (28): 13- 24.
23	Weisman M L , Klemp J B . The dependence of numerically simulated convective storms on vertical wind shear and buoyancy[J]. Monthly Weather Review, 1982, 110 (6): 504- 520.
24	McCaul Jr E W . Buoyancy and shear characteristics of hurricane-tornado environments[J]. Monthly Weather Review, 1991, 119 (8): 1954- 1978.
25	Davies-Jones R . Streamwise vorticity:The origin of updraft rotation in supercell storms[J]. Journal of the Atmospheric Sciences, 1984, 41 (20): 2991- 3006.
26	黄先香, 俞小鼎, 炎利军, 等. 广东两次台风龙卷的环境背景和雷达回波对比[J]. 应用气象学报, 2018, 29 (1): 70- 83.
27	徐璐璐, 李倩, 李慧琳, 等. 2018年9月丹东连续两次风雹天气的多尺度对比分析[J]. 气象与环境学报, 2019, 35 (6): 1- 7.
28	单乃超, 周后福, 褚保亮, 等. 2017年5月14日合肥地区雷暴大风过程机理分析[J]. 气象与环境学报, 2019, 35 (5): 1- 9.

[1]	WANG Xiu-juan,JIANG Zhong-bao,YANG Jie-fan, XIA Wei, ZHANG Chao. Numerical simulation on microphysical mechanism of stratiform cloud precipitation in Hebei province[J]. Journal of Meteorology and Environment, 2014, 30(1): 1 -7 .
[2]	FANG Chun-chun, GUAN Chun-ling. Numerical simulation on hail weather caused by meso-scale vortex inside cold vortex over northeastern China[J]. Journal of Meteorology and Environment, 2014, 30(1): 8 -14 .
[3]	. [J]. Journal of Meteorology and Environment, 2005, 21(4): 43 -44 .
[4]	. [J]. Journal of Meteorology and Environment, 2002, 18(1): 32 -33 .
[5]	. [J]. Journal of Meteorology and Environment, 2005, 21(1): 1 -3 .
[6]	ZHOU Qixing . Advance in the effects of climate change on environment and health[J]. Journal of Meteorology and Environment, 2006, 22(1): 38 -44 .
[7]	. [J]. Journal of Meteorology and Environment, 2001, 17(2): 43 -44 .
[8]	. [J]. Journal of Meteorology and Environment, 2003, 19(1): 38 .
[9]	. [J]. Journal of Meteorology and Environment, 2003, 19(2): 31 -32 .
[10]	. [J]. Journal of Meteorology and Environment, 2000, 16(3): 53 -54 .

损毁级别	灾情描述	风速期望值	风速最小值	风速最大值	期望值对应的EF级别
1	可计损失的起始值	30.0	24.0	37.1	EF0
2	卷叶门向内或向外垮塌	39.8	33.5	48.3	EF1
3	铁制的屋顶或墙体铁板吹飞	42.5	34.9	53.6	EF1
4	柱锚固脱落	52.3	42.9	60.3	EF2
5	房顶的檩条垮塌	52.7	42.5	61.7	EF2
6	侧面X型负载支架倒塌	61.9	52.7	70.6	EF3
7	房屋的钢架结构垮塌	63.9	53.6	75.1	EF3
8	整个房屋完全垮塌	69.3	59.0	79.6	EF3

环境参数	清远	香港
对流有效位能/(J·kg^-1)	26.4	1694.4
对流抑制/(J·kg^-1)	0.1	2.1
抬升凝结高度/m	0	116
0—1 km风垂直切变/(10^-3·s^-1)	14.2	13.1
0—6 km风垂直切变/(10^-3·s^-1)	2.3	2.5
风暴相对螺旋度/(m²·s²)	364	237
