大连地区ECMWF细网格10 m风场与观测实况对比与检验

doi:10.3969/j.issn.1673-503X.2021.01.010

Abstract

Abstract:

The 10-m wind data of European Center for Medium-Range Weather (ECMWF)fine mesh grid from January of 2016 to December of 2018 were evaluated using various observations from 8 national meteorological observation stations in Dalian.The results indicated that the 10 m wind forecast of ECMWF fine mesh grid is the closest to the maximum wind speed, and has the best correlation with the maximum instantaneous wind speed.The whole forecast results of ECMWF 10 m wind speed for eight stations in Dalian are relatively larger on average.From the error statistical analysis between ECMWF 10 m wind forecast data and its corresponding maximum wind speed, the results showed that forecast is closest to the observation when the wind is at level 3, larger than observations when the wind is below level 3, and smaller than that when the wind is above level 3 by the classification of the observation data from the mean error (ME) of wind speed.The wind speed errors of different directions are also obvious, but smaller than those of different wind scales.Mean absolute error (MAE) is the smallest when the wind is between levels 2 and 3.There is no significant difference in ME during all the forecast times, which is mainly between 0.1-0.3 m·s^-1.But MAE increases slowly with the extension of forecast time.The wind speed errors had obvious diurnal variations, which show the characteristics of small in the day and large at night, the smallest in the afternoon, and the largest after midnight.They also vary at different stations, wind levels, and wind directions.

Key words: Maximum wind, Mode verification, Diurnal variation

CLC Number:

P425

Jing-tai YANG,Yu-xiu SUI,Jian XIAO,Li-na WANG,Hui-lin CHANG,Xiao-dong WU,Yan WANG. Comparison and verification of 10-m wind field based on ECMWF fine grid and observations in Dalian[J]. Journal of Meteorology and Environment, 2021, 37(1): 73-81.

Figures/Tables 11

Fig.1

Table 1

Table 2

Table 3

Fig.2

Fig.3

Table 4

Table 5

Table 6

Fig.4

Table 7

References 24

1	顾婷婷, 李晓丽, 刘丹妮, 等. 舟山跨海大桥一次强冷空气过程的精细化风场模拟[J]. 高原气象, 2018, 37 (4): 1074- 1082.
2	孟莹莹, 曹殿斌, 吴岩, 等. 大小兴安岭林区风场动力降尺度对比研究[J]. 气象与环境学报, 2019, 35 (4): 8- 15.
3	夏凡, 杨晓霞, 刘诗军, 等. WRF模式2 m温度在山东预报效果的评估[J]. 气象与环境学报, 2019, 35 (5): 10- 17.
4	姜平, 刘晓冉, 朱浩楠, 等. 复杂地形下局地山谷风环流的理想数值模拟[J]. 高原气象, 2019, 38 (6): 1272- 1282.
5	李俊徽, 耿焕同, 谢佩妍, 等. 基于WRF-CALMET的精细化方法在大风预报上的应用研究[J]. 气象, 2017, 43 (8): 1005- 1015.
6	蔡晓杰, 戴建华, 朱智慧, 等. 上海沿岸海域风场质量控制与预报检验[J]. 气象科技, 2019, 47 (2): 214- 221.
7	周荣卫, 何晓凤. 新疆哈密复杂地形风场的数值模拟及特征分析[J]. 高原气象, 2018, 37 (5): 1413- 1427.
8	潘留杰, 张宏芳, 陈小婷, 等. ECMWF集合预报在中国中部地区的降水概率预报性能评估[J]. 高原气象, 2017, 36 (1): 138- 147.
9	傅朝, 刘维成, 杨晓军, 等. 强对流临近预警中集合预报成员的即时分析——以陇东一次暴雨过程ECMWF集合预报应用为例[J]. 高原气象, 2019, 38 (1): 143- 155.
10	王丹, 王建鹏, 白庆梅, 等. 递减平均法与一元线性回归法对ECMWF温度预报订正能力对比[J]. 气象, 2019, 45 (9): 1310- 1321.
11	徐燚, 钱浩, 罗玲, 等. 基于ECMWF模式预报的台风降水地形订正方法[J]. 气象学报, 2019, 77 (4): 674- 685.
12	Nishimura M , Yamaguchi M . Selective ensemble mean technique for tropical cyclone track forecasts using multi-model ensembles[J]. Tropical Cyclone Research and Review, 2015, 4 (2): 71- 78.
13	姜皓严. ASCAT洋面卫星反演风场资料与数值模式10米预报风场的对比分析[D]. 兰州: 兰州大学, 2017, 1-57.
14	曾瑾瑜, 刘爱鸣, 高珊, 等. 福建省沿海冬半年东北大风的数值预报释用方法研究[J]. 海洋预报, 2015, 32 (5): 61- 68.
15	吴俞, 冯文, 李勋, 等. ECMWF细网格10 m风场产品在南海海域的预报检验[J]. 西南师范大学学报: 自然科学版, 2015, 40 (9): 204- 212.
16	潘留杰, 张宏芳, 朱伟军, 等. ECMWF模式对东北半球气象要素场预报能力的检验[J]. 气候与环境研究, 2013, 18 (1): 111- 123.
17	刘彬贤, 陈宏, 左涛, 等. 基于EC集合预报的渤海灾害性大风风速预报方法研究[J]. 海洋预报, 2018, 35 (2): 19- 26.
18	胡海川, 黄彬, 魏晓琳. 我国近海洋面10 m风速集合预报客观订正方法[J]. 气象, 2017, 43 (7): 856- 862.
19	任晨辰, 段明铿. ECMWF全风速场集合预报结果的偏差订正与预报不一致性分析[J]. 大气科学学报, 2019, 42 (3): 360- 369.
20	石岚, 徐丽娜, 郝玉珠. 基于风速高相关分区的风电场风速预报订正[J]. 应用气象学报, 2016, 27 (4): 506- 512.
21	王焕毅, 谭政华, 杨萌, 等. 三种数值模式气温预报产品的检验及误差订正方法研究[J]. 气象与环境学报, 2018, 34 (1): 22- 29.
22	敖雪, 翟晴飞, 崔妍, 等. 1971-2015年辽宁省海岸带大风时空分布特征及成因分析[J]. 气象与环境学报, 2018, 34 (5): 108- 118.
23	程攀, 孙虹雨, 陈传雷, 等. 高频地波雷达在辽宁省海上大风预警中的应用研究[J]. 气象与环境学报, 2017, 33 (5): 25- 34.
24	于志明, 王驷鹞, 马冬亮. 渤海海洋气象灾害天气分型与预报指标研究[J]. 气象与环境学报, 2018, 34 (1): 106- 111.

名称	含义和算法	类别
瞬时风速	风速每秒采样1次，正点前3 s的平均值	阵风
2 min平均风速	风速每秒采样1次，正点前120 s的平均值	平均风
10 min平均风速	风速每秒采样1次，先求出以1 s为步长，每1 min的平均值，然后再以1 min为步长，求正点前10 min的平均值	平均风
极大风速	正点前1 h内的最大瞬时风速	阵风
最大风速	正点前1 h的最大10 min平均风速	平均风

类别		00	12	24	36	48	60	72	84	96	108	120
	ME	-0.2	-0.1	-0.2	-0.2	-0.2	-0.2	-0.2	-0.2	-0.2	-0.1	-0.2
瞬时风速	MAE	1.5	1.6	1.6	1.7	1.7	1.7	1.8	1.8	1.9	1.9	1.9
	r	0.711	0.693	0.671	0.654	0.641	0.622	0.610	0.591	0.566	0.527	0.509
	ME	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9
2 min平均风速	MAE	1.5	1.5	1.5	1.6	1.6	1.6	1.6	1.7	1.7	1.8	1.8
	r	0.681	0.663	0.642	0.625	0.613	0.594	0.584	0.566	0.541	0.503	0.487
	ME	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9
10 min平均风速	MAE	1.4	1.5	1.5	1.5	1.5	1.6	1.6	1.6	1.7	1.7	1.8
	r	0.698	0.679	0.657	0.640	0.628	0.609	0.598	0.579	0.554	0.515	0.499
	ME	-2.1	-2.1	-2.1	-2.1	-2.1	-2.1	-2	-2	-2	-2	-2
极大风速	MAE	2.5	2.5	2.5	2.5	2.6	2.6	2.6	2.6	2.7	2.7	2.7
	r	0.756	0.739	0.718	0.700	0.685	0.667	0.657	0.635	0.610	0.567	0.550
	ME	0.2	0.2	0.2	0.2	0.1	0.1	0.2	0.2	0.2	0.2	0.2
最大风速	MAE	1.3	1.3	1.3	1.4	1.4	1.4	1.4	1.5	1.5	1.6	1.6
	r	0.711	0.694	0.673	0.656	0.642	0.624	0.617	0.595	0.57	0.531	0.514

类别		132	144	156	168	180	192	204	216	228	240
	ME	-0.1	-0.1	-0.1	-0.1	-0.1	-0.1	-0.1	-0.2	-0.2	0.1
瞬时风速	MAE	2	2.1	2.1	2.2	2.3	2.3	2.3	2.4	2.4	2.3
	r	0.479	0.440	0.401	0.368	0.323	0.299	0.270	0.245	0.241	0.211
	ME	0.9	0.9	0.9	1	1	1	0.9	0.9	0.9	1.1
2 min平均风速	MAE	1.8	1.9	1.9	2	2.1	2.1	2.1	2.1	2.1	2.1
	r	0.456	0.420	0.383	0.351	0.307	0.284	0.256	0.233	0.228	0.199
	ME	0.9	1	1	1	1	1	0.9	0.9	0.9	1.1
10 min平均风速	MAE	1.8	1.9	1.9	2	2	2.1	2.1	2.1	2.1	2.1
	r	0.469	0.431	0.393	0.360	0.314	0.289	0.262	0.238	0.234	0.203
	ME	-2	-2	-2	-2	-2	-2	-2	-2.1	-2	-1.6
极大风速	MAE	2.8	2.8	2.9	2.9	3	3	3.1	3.1	3.1	2.9
	r	0.518	0.478	0.434	0.403	0.352	0.324	0.287	0.263	0.258	0.224
	ME	0.2	0.2	0.2	0.2	0.3	0.3	0.2	0.2	0.2	0.4
最大风速	MAE	1.7	1.7	1.8	1.8	1.9	1.9	2	2	2	2
	r	0.483	0.445	0.405	0.376	0.329	0.304	0.270	0.249	0.244	0.207

类别	1级	2级	3级	4级	5级	6级	7级	8级	9级	10级	11级
瞬时风速	0.12	0.192	0.18	0.213	0.243	0.215	0.091^*	0.211^*	-0.305^*	-	-
2 min平均风速	0.17	0.235	0.228	0.249	0.226	0.219	0.242^*	-0.267^*	-	-	-
10 min平均风速	0.181	0.241	0.232	0.248	0.207	0.266	0.121^*	-	-	-	-
极大风速	0.006^*	0.177	0.155	0.208	0.251	0.229	0.195	0.166	0.3^*	0.032^*	-0.126^*
最大风速	0.081	0.234	0.246	0.281	0.214	0.229	0.45	-0.817^*	-	-	-

风向	1级	2级	3级	4级	5级	6级	7级	8级
N	1.4	0.8	0.5	0.1	-0.8	-2.7	-4.7	-
NE	1.1	0.7	0.3	-0.4	-1.2	-2.4	-3.5	-
E	1	0.3	-0.6	-1.9	-2.7	-2.9	-	-
SE	1.1	0.5	-0.5	-1.4	-2.8	-4.6	-	-
S	1.2	0.8	0	-0.5	-1.2	-1	-	-
SW	1.2	0.8	0	-0.9	-2.2	-4	-	-
W	1.2	0.7	-0.3	-1.2	-2.3	-2.8	-3.3	-
NW	1	0.6	-0.2	-1.2	-1.9	-1.9	-2.4	-5.5
平均差	1.2	0.7	-0.1	-0.7	-1.5	-2.6	-3.6	-5.5

站点	北风	东北风	东风	东南风	南风	西南风	西风	西北风
大连	0.6	1.1	1.2	1.1	0.6	0.8	1.8	1.2
旅顺	0.1	0.6	0.9	0.5	1	0.8	-0.2	0.5
金州	-1.1	-0.6	-1	-0.9	-0.6	0.6	0.4	-0.7
长海	1.6	1.1	1.5	1.1	0.9	0.8	1.4	2.2
瓦房店	-0.3	0	0.2	-0.4	0.1	0.3	-0.9	-1.1
普兰店	0.4	0.7	-0.5	-0.4	0.2	-0.7	-0.7	-0.5
庄河	1.3	0.8	0.3	0.3	0.4	0.6	0.9	1.0
长兴岛	-0.1	-0.6	-0.4	-1.1	-1.1	-0.8	-0.1	0.4
平均	0.4	0.4	-0.1	-0.2	0.3	0.2	0.1	0.0

Comparison and verification of 10-m wind field based on ECMWF fine grid and observations in Dalian

RichHTML

PDF (PC)

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 11

References 24

Related Articles 4

Metrics

Comments

Recommended 10

起报时次	误差类型	00	12	24	36	48	60	72	84	96	108	120
08	ME	-0.1	-0.1	-0.1	-0.1	-0.1	-0.1	0	0	0.1	0	0.1
20	ME	0.4	0.4	0.4	0.4	0.4	0.4	0.3	0.3	0.3	0.4	0.3
08	MAE	1.3	1.3	1.4	1.4	1.4	1.5	1.5	1.5	1.6	1.6	1.7
20	MAE	1.2	1.3	1.3	1.3	1.4	1.4	1.4	1.4	1.5	1.5	1.5
