能见度观测方式改变对京津冀地区雾霾判识及统计的影响分析

doi:10.3969/j.issn.1673-503X.2023.01.007

Abstract

Abstract:

Based on the visibility and conventional ground observation data of 177 stations in the Beijing-Tianjin-Hebei region during the period from 2000 to 2018 which is divided into three stages of 2000-2013, 2014, and 2015-2020 when the human visual measurement (HM), the instrumental derived measurement (IM) and the joint observation of HM and IM are adopted, respectively, the visibilities measured by HM and IM were compared and analyzed.The cold and the warm season were respectively defined as the period from November to April of the following year and from May to October.The results show that the annual average visibilities measured by IM at 08:00 and 14:00 are lower than those measured by HM.In the cold season, the measured monthly average visibility at 08:00 by IM is lower than that by HM, and the difference between two methods at 14:00 is significantly smaller than at 08:00.In the warm season, the visibility at 08:00 measured by IM is lower than that by HM, but the difference is generally lower than that in the cold season and is the smallest in May.In 2014, fog and haze occur frequently from January to April.The visibilities at 08:00 and 14:00 measured by IM are obviously less than those by HM.From May to December when there is less haze, the visibilities of more than half stations measured by IM are greater than those by HM.When the visibility is below 12 km, the measured values by IM are less than those by HM, and when the visibility is above the 12 km, the measured values by IM are greater than those by HM.When the visibility is less than 1 km, the measured values by IM are close to those by HM.There is an inverse correlation between visibility and relative humidity.When the visibility is less than 0.5 km, the relative humidities measured by IM and HM range from 93% to 96%, but with the increase of visibility, the relative humidity measured by IM is more scattered than that by HM.After the observation is changed from HM to IM, the occurrence frequencies of fog and haze increase obviously, especially for haze.The high incidence area of fog measured by IM and HM both are distributed along the Beijing-Guangzhou railway in the Beijing-Tianjin-Hebei region, but the haze high incidence area moves eastward from the shallow mountain area of the south-central Taihang Mountain to the plain to the line of Beijing-Guangzhou Railway.

Key words: Visibility, Observation method, Fog, Haze, Relative humidity

CLC Number:

P427.2

Gang ZHU,Jiang-bo LI,Zhuo SUN,Shuo-fei WANG. Influence of the change of visibility observation method on the statistics and identification of fog and haze in the Beijing-Tianjin-Hebei region[J]. Journal of Meteorology and Environment, 2023, 39(1): 55-64.

Figures/Tables 11

Fig.1

Table 1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

Fig.10

References 22

1	佘元标, 黄殷, 郑贵生. 饶平站能见度仪器测量与人工观测对比分析[J]. 广东气象, 2013, 35 (1): 77- 80.
2	夏冬, 吴志权, 谭浩波, 等. 广东省能见度自动观测系统资料评估分析与订正[J]. 气象科技, 2014, 42 (1): 68- 72.
3	杜传耀, 乔晓燕, 张小兵, 等. 能见度人工观测与新型站仪器测量的对比分析[J]. 气象水文海洋仪器, 2014, 31 (4): 42- 44.
4	王瑞, 周学东, 李崇志, 等. 江苏省能见度的人工与自动观测差异分析[J]. 气象科学, 2015, 35 (2): 183- 188.
5	任律, 樊高峰, 黄立丹. 浙江省人工观测与仪器观测能见度对比分析[J]. 浙江气象, 2015, 36 (2): 41- 45.
6	谭浩波, 陈欢欢, 吴兑, 等. Model 6000型前向散射能见度仪性能评估及数据订正[J]. 热带气象学报, 2010, 26 (6): 687- 693.
7	吴华斌, 黄小丹, 莫春玲. M6000型能见度仪与人工观测能见度差值分析[J]. 气象科技, 2015, 43 (4): 595- 600.
8	司鹏, 高润祥. 天津雾和霾自动观测与人工观测的对比评估[J]. 应用气象学报, 2015, 26 (2): 240- 246.
9	明虎, 陈丽杰, 高联辉, 等. 机场低能见度自动观测设备测量数据对比[J]. 应用气象学报, 2015, 26 (6): 750- 758.
10	姜江, 郭文利, 王春玲. 2007—2015年北京地区能见度时空变化特征[J]. 气象与环境学报, 2019, 35 (1): 45- 52.
11	Idris N , Maswati M , Usmawanda T N , et al. Effect of temperature and humidity on the visibility of mirage on the runway of sultan Iskandar Muda Airport, Aceh, Indonesia[J]. Journal of Physics and Its Applications, 2019, 2 (1): 67- 71.
12	姜江, 张国平, 高金兵. 北京大气能见度的主要影响因子[J]. 应用气象学报, 2018, 29 (2): 188- 199.
13	刘兆东, 王宏, 沈新勇, 等. 京津冀及周边地区冬季能见度与PM_2.5浓度和环境湿度的多元回归分析[J]. 气象学报, 2020, 78 (4): 679- 690.
14	吴杰, 周建平, 邓学良, 等. 巢湖地区能见度特征及其影响因子分析[J]. 气象与环境学报, 2019, 35 (2): 40- 45.
15	李江波, 赵玉广, 孔凡超, 等. 华北平原连续性大雾的特征分析[J]. 中国海洋大学学报(自然科学版), 2010, 40 (7): 15- 23.
16	吴雁, 王荣英, 李江波, 等. 1960—2013年河北省雾霾天气变化特征[J]. 干旱气象, 2017, 35 (3): 391- 397.
17	王博妮, 张雪蓉, 孙明, 等. 江苏地区雨雾天气特征及成因研究[J]. 气象与环境学报, 2020, 36 (1): 58- 66.
18	张翠艳, 阎琦, 白雪, 等. 1999—2018年锦州地区大雾气候特征及成因分析[J]. 气象与环境学报, 2020, 36 (3): 87- 92.
19	尤琦, 曲晓黎, 赵增保, 等. 基于CART决策树的河北省低能见度分类研究[J]. 气象与环境学报, 2022, 38 (4): 112- 118.
20	中国气象局. 地面气象观测规范[M]. 北京: 气象出版社, 2003.
21	李江波, 杨晓亮, 连志鸾. 京津冀雾和霾预报[M]. 北京: 气象出版社, 2020: 148- 149.
22	李秋芳, 任振科. 石家庄市区PM_2.5时空分布特征[J]. 河北工业科技, 2017, 34 (1): 64- 70.

时段	人工观测判识标准			自动观测判识标准
时段	霾	雾	轻雾	霾	雾	轻雾
建站至2013年1月	VIS＜10 km，RH≤60%	VIS＜1 km，RH≥80%	1 km≤VIS＜10 km，RH>60%	—	—	—
2013年2— 12月	VIS＜10 km，RH＜80%	VIS＜1 km，RH≥80%	1 km≤VIS＜10 km，RH≥80%	VIS＜10 km，RH＜80%	VIS＜1 km，RH≥80%	1 km≤VIS＜10 km，RH>80%
2014年1月	VIS＜10 km，RH＜80%	VIS＜1 km，RH≥80%	1 km≤VIS＜10 km，RH≥80%	VIS＜7.5 km，RH＜80%	VIS＜0.75 km，RH≥80%	0.75 km≤VIS＜7.5km，RH>80%
2014年2月至今	VIS＜10 km，RH≤60%	VIS＜1 km，RH≥80%	1 km≤VIS＜10 km，RH>60%	VIS＜7.5 km，RH≤60%，持续6个时次	VIS＜0.75 km，RH≥80%	0.75 km≤VIS＜7.5km，RH>60%，持续6个时次
