SSPs情景下福建省未来极端降水的模拟与预估

doi:10.3969/j.issn.1673-503X.2023.01.004

Abstract

Abstract:

Based on the daily precipitation data under the SSPs (Shared Socioeconomic Pathways) emission scenarios from the latest generation CMIP6 (Coupled Model Intercomparison Project Phase 6) global climate models and high-resolution daily grid observation data, the performance of the models was evaluated using the Taylor diagrams and Quantile-Mapping method.Eight extreme precipitation indices for the near (2021-2040), middle (2051-2070), and late (2081-2100) periods of the 21st century were calculated and analyzed under the SSP2-4.5 and SSP5-8.5 scenarios.The results show that in the reference period (1991-2010), after the Quantile-Mapping method correction, the simulation of each extreme precipitation index is closer to the observation, and the spatial correlation coefficient, root mean square error, and standard deviation are greatly improved.For each stage of the 21st century, both the annual cumulative precipitation (Prcptot) and the number of extreme rainstorm days (R50mm) in Fujian province are higher than those during the reference period (1991-2010), and larger the increase in the later stage under the high emission scenario.The number of precipitation days larger than 10mm (R10mm) and the number of extremely heavy rain days (R20mm) increases and decreases in different ways.R10mm shows a decreasing trend in the northeastern part of Fujian province and an increasing trend in most other areas.R20mm shows a decreasing trend in the northwestern part of Fujian province in the recent 21st century under SSP2-4.5 scenarios, but an increasing trend in other scenarios and time periods.The maximum 1 d precipitation (Rx1day), maximum consecutive 5 d precipitation (Rx5day) and daily precipitation intensity index (SDII), which represent the precipitation intensity, will all increase in the future, and the increase rate in coastal areas is higher than that in inland areas.The continuous dryness index (CDD) increases in most areas, which indicates that the extreme precipitation and continuous dryness will increase together in Fujian province in the future, and the probability of extreme drought and flood events will increase significantly.

Key words: SSPs scenarios, Extreme precipitation events, Climate change, Climate projection

CLC Number:

P467

Zhen-fei TANG,Ting YANG,Xiao-chen CHEN,Xin-xin LI,Xin LIN,Fen HE,Zhen-zhi WEN. Simulation and prediction of future extreme precipitation in Fujian province under SSPs scenarios[J]. Journal of Meteorology and Environment, 2023, 39(1): 26-36.

Figures/Tables 12

Table 1

Table 2

Fig.1

Fig.2

Table 3

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

References 45

1	IP CC . Climate change 2013:The physical science basis: working group Ⅰ contribution to the fifth assessment report of the intergovernmental panel on climate change[M]. Cambridge: Cambridge University Press, 2013.
2	Meehl G A , Arblaster J M , Tebaldi C . Understanding future patterns of increased precipitation intensity in climate model simulations[J]. Geophysical Research Letters, 2005, 32 (18): L18719.
3	Allen M R , Ingram W J . Constraints on future changes in climate and the hydrologic cycle[J]. Nature, 2002, 419 (6903): 224- 232. doi: 10.1038/nature01092
4	Ziegler A D , Sheffield J , Maurer E P , et al. Detection of intensification in global-and continental-scale hydrological cycles: temporal scale of evaluation[J]. Journal of Climate, 2003, 16 (3): 535- 547. doi: 10.1175/1520-0442(2003)016<0535:DOIIGA>2.0.CO;2
5	You Q L , Kang S C , Aguilar E , et al. Changes in daily climate extremes in China and their connection to the large scale atmospheric circulation during 1961-2003[J]. Climate Dynamics, 2011, 36 (11/12): 2399- 2417.
6	Li J , Zhao Y , Tang Z F . Projection of Future summer precipitation over the Yellow River Basin: a moisture budget perspective[J]. Atmosphere, 2020, 11 (12): 1307. doi: 10.3390/atmos11121307
7	许佳琦, 周永吉, 姜丽霞, 等. 1965—2014年黑龙江省洪涝灾害时空演变特征[J]. 气象与环境学报, 2020, 36 (3): 41- 48. doi: 10.3969/j.issn.1673-503X.2020.03.006
8	Easterling D R , Evans J L , Groisman P Y , et al. Observed variability and trends in extreme climate events: a brief review[J]. Bulletin of the American Meteorological Society, 2000, 81 (3): 417- 426. doi: 10.1175/1520-0477(2000)081<0417:OVATIE>2.3.CO;2
9	Zhai P M , Zhang X B , Wan H , et al. Trends in total precipitation and frequency of daily precipitation extremes over China[J]. Journal of Climate, 2005, 18 (7): 1096- 1108. doi: 10.1175/JCLI-3318.1
10	江志红, 陈威霖, 宋洁, 等. 7个IPCC AR4模式对中国地区极端降水指数模拟能力的评估及其未来情景预估[J]. 大气科学, 2009, 33 (1): 109- 120. doi: 10.3878/j.issn.1006-9895.2009.01.10
11	林昕, 高建芸, 张容焱, 等. 基于定量化指标的福建前汛期降水强度特征分析[J]. 暴雨灾害, 2014, 33 (3): 297- 303. doi: 10.3969/j.issn.1004-9045.2014.03.013
12	IP CC . Climate change 2007:The physical science basis[M]. Cambridge: Cambridge University Press, 2007.
13	敖雪, 翟晴飞, 崔妍, 等. 不同升温情景下中国东北地区平均气候和极端气候事件变化预估[J]. 气象与环境学报, 2020, 36 (5): 40- 51. doi: 10.3969/j.issn.1673-503X.2020.05.006
14	尹晓东, 董思言, 韩振宇, 等. 未来50a长江三角洲地区干旱和洪涝灾害风险预估[J]. 气象与环境学报, 2018, 34 (5): 66- 75. doi: 10.3969/j.issn.1673-503X.2018.05.009
15	尹红, 孙颖. 基于ETCCDI指数2017年中国极端温度和降水特征分析[J]. 气候变化研究进展, 2019, 15 (4): 363- 373.
16	Alexander L V , Zhang X , Peterson T C , et al. Global observed changes in daily climate extremes of temperature and precipitation[J]. Journal of Geophysical Research: Atmospheres, 2006, 111 (Z5): D05109.
17	Sillmann J , Roeckner E . Indices for extreme events in projections of anthropogenic climate change[J]. Climatic Change, 2008, 86 (1/2): 83- 104.
18	Sillmann J , Kharin V V , Zwiers F W , et al. Climate extremes indices in the CMIP5 multimodel ensemble: part 2.Future climate projections[J]. Journal of Geophysical Research: Atmospheres, 2013, 118 (6): 2473- 2493. doi: 10.1002/jgrd.50188
19	Andrys J , Kala J , Lyons T J . Regional climate projections of mean and extreme climate for the Southwest of western Australia (1970-1999 compared to 2030-2059)[J]. Climate Dynamics, 2017, 48 (5/6): 1723- 1747.
20	Akinsanola A A , Kooperman G J , Pendergrass A G , et al. Seasonal representation of extreme precipitation indices over the United States in CMIP6 present-day simulations[J]. Environmental Research Letters, 2020, 15 (9): 094003. doi: 10.1088/1748-9326/ab92c1
21	任正果, 张明军, 王圣杰, 等. 1961-2011年中国南方地区极端降水事件变化[J]. 地理学报, 2014, 69 (5): 640- 649.
22	郭湘宇, 吴正方, 杜海波, 等. 福建省极端降水时空变化特征及其环流因素分析[J]. 资源科学, 2017, 39 (6): 1084- 1098.
23	Moss R H , Edmonds J A , Hibbard K A , et al. The next generation of scenarios for climate change research and assessment[J]. Nature, 2010, 463 (7282): 747- 756. doi: 10.1038/nature08823
24	张海娜, 侯依玲, 赵春雨, 等. CCSM4模式对东北气温和降水的模拟及预估[J]. 气象与环境学报, 2019, 35 (1): 72- 78. doi: 10.3969/j.issn.1673-503X.2019.01.010
25	Jiang Z H , Li W , Xu J J , et al. Extreme precipitation indices over China in CMIP5 models.Part Ⅰ: model evaluation[J]. Journal of Climate, 2015, 28 (21): 8603- 8619. doi: 10.1175/JCLI-D-15-0099.1
26	陈活泼. CMIP5模式对21世纪末中国极端降水事件变化的预估[J]. 科学通报, 2013, 58 (8): 743- 752.
27	吴佳, 周波涛, 徐影. 中国平均降水和极端降水对气候变暖的响应: CMIP5模式模拟评估和预估[J]. 地球物理学报, 2015, 58 (9): 3048- 3060.
28	周文翀, 韩振宇. CMIP5全球气候模式对中国黄河流域气候模拟能力的评估[J]. 气象与环境学报, 2018, 34 (6): 42- 55.
29	Eyring V , Bony S , Meehl G A , et al. Overview of the coupled model intercomparison project phase 6(CMIP6)experimental design and organization[J]. Geoscientific Model Development, 2016, 9 (5): 1937- 1958.
30	赵宗慈, 罗勇, 黄建斌. 从检验CMIP5气候模式看CMIP6地球系统模式的发展[J]. 气候变化研究进展, 2018, 14 (6): 643- 648.
31	张丽霞, 陈晓龙, 辛晓歌. CMIP6情景模式比较计划(ScenarioMIP)概况与评述[J]. 气候变化研究进展, 2019, 15 (5): 519- 525.
32	周天军, 邹立维, 陈晓龙. 第六次国际耦合模式比较计划(CMIP6)评述[J]. 气候变化研究进展, 2019, 15 (5): 445- 456.
33	周天军, 陈梓明, 邹立维, 等. 中国地球气候系统模式的发展及其模拟和预估[J]. 气象学报, 2020, 78 (3): 332- 350.
34	Chen H P , Sun J Q , Lin W Q , et al. Comparison of CMIP6 and CMIP5 models in simulating climate extremes[J]. Science Bulletin, 2020, 65 (17): 1415- 1418.
35	Xin X G , Wu T W , Zhang J , et al. Comparison of CMIP6 and CMIP5 simulations of precipitation in China and the East Asian summer monsoon[J]. International Journal of Climatology, 2020, 40 (15): 6423- 6440.
36	Fu Y H , Lin Z D , Wang T . Simulated relationship between wintertime ENSO and East Asian summer rainfall: from CMIP3 to CMIP6[J]. Advances in Atmospheric Sciences, 2021, 38 (2): 221- 236.
37	Jiang D B , Hu D , Tian Z P , et al. Differences between CMIP6 and CMIP5 models in simulating climate over China and the East Asian monsoon[J]. Advances in Atmospheric Sciences, 2020, 37 (10): 1102- 1118.
38	Zhu H H , Jiang Z H , Li J , et al. Does CMIP6 inspire more confidence in simulating climate extremes over China?[J]. Advances in Atmospheric Sciences, 2020, 37 (10): 1119- 1132.
39	向竣文, 张利平, 邓瑶, 等. 基于CMIP6的中国主要地区极端气温/降水模拟能力评估及未来情景预估[J]. 武汉大学学报(工学版), 2021, 54 (1): 46- 57. 46-57, 87
40	苏志重, 石顺吉, 张伟, 等. 1960—2010年福建省极端降水事件变化趋势分析[J]. 暴雨灾害, 2016, 35 (2): 166- 172.
41	吴佳, 高学杰. 一套格点化的中国区域逐日观测资料及与其它资料的对比[J]. 地球物理学报, 2013, 56 (4): 1102- 1111.
42	Zhu H H , Jiang Z H , Li L . Projection of climate extremes in China, an incremental exercise from CMIP5 to CMIP6[J]. Science Bulletin, 2021, 66 (24): 2528- 2537.
43	Taylor K E . Summarizing multiple aspects of model performance in a single diagram[J]. Journal of Geophysical Research: Atmospheres, 2001, 106 (Z7): 7183- 7192.
44	童尧, 高学杰, 韩振宇, 等. 基于RegCM4模式的中国区域日尺度降水模拟误差订正[J]. 大气科学, 2017, 41 (6): 1156- 1166.
45	Zhou T J , Yu R C . Twentieth-Century surface air temperature over China and the globe simulated by coupled climate models[J]. Journal of Climate, 2006, 19 (22): 5843- 5858.

序号	模式简称	研究机构	分辨率
1	BCC-CSM2-MR	中国气象局国家气候中心(BCC)	1.125°×1.125°
2	EC-Earth3-Veg	欧盟地球系统模式联盟	0.7°×0.7°
3	GFDL-ESM4	美国大气与海洋管理局地球物理流体动力实验室(GFDL)	1.0°×1.25°
4	IPSL-CM6A-LR	法国皮埃尔—西蒙拉普斯研究所(IPSL)	1.26°×2.5°
5	MRI-ESM2-0	日本气象研究所(MRI)	1.125°×1.125°
6	NorESM2-MM	挪威气候中心(NCC)	0.94°×1.25°

指数名称	代码	定义	单位
年累积降水量	Prcptot	日降水量≥ 1 mm的年累积降水量	mm
大雨日数	R10mm	日降水量≥ 10 mm的总日数	d
极端大雨日数	R20mm	日降水量≥ 20 mm的总日数	d
极端暴雨日数	R50mm	日降水量≥50 mm的总日数	d
最大1日降水量	RX1day	最大日降水量	mm
最大5日降水量	RX5day	最大连续5 d降水量	mm
日降水强度	SDII	日降水总量与降水日数之比	mm·d^-1
持续干燥指数	CDD	日降水量＜1 mm的最长连续日数	d

指数	SSP2-4.5			SSP5-8.5
指数	2021—2040年	2051—2070年	2081—2100年	2021—2040年	2051—2070年	2081—2100年
Prcptot/(%)	5.26	7.02	10.25	6.43	7.21	17.46
R10mm/d	-0.16	0.69	2.32	0.84	0.92	3.17
R20mm/d	0.28	0.82	1.61	0.77	0.66	2.98
R50mm/d	0.50	0.67	0.86	0.42	0.76	2.19
RX1day/(%)	18.46	18.52	24.01	16.49	19.81	46.60
RX5day/(%)	18.29	18.59	19.79	13.80	16.99	37.19
SDII/(%)	3.52	5.79	7.60	3.50	6.02	17.29
CDD/(%)	3.05	4.17	2.26	0.54	3.44	3.65
